1x8 HDMI Splitter HDbitT over IP Extender Kit

Overview

Features Applications Need to Know Before Buying Overview Extends 1080p HDMI signal up to 394ft over Cat6 cable to up to 8 displays, IR control, works with Gigabit network switches for more displays and extension Features Extend HDMI audio and video signals up to 394ft (120m) via Cat5e/6 cable for remote display/monitor using best network transport protocol and IR remote control of source devices What is HDbitT? HDbitT is a new generation audio/video digital connection transmission protocol solution. Provides stable performance, long-distance transmission, and high-definition signal Extend Distance This 1x8 HDMI Splitter HDbitT over IP Extender is designed for transmission/security, up to 394ft (120m) per each HDMI signal through HDbitT protocol and Gigabit Ethernet switch to the remote HDMI displays High Performance Offers a true 10.2Gbps video bandwidth and supports stereo audio Full HD Resolution Supports high-definition video resolution up to 1080p (1920x1080) @60Hz, HDCP 1.2 to deliver a clear picture quality IR Extension IR pass-through feature allows remote control of the HDMI source device and playback function at the remote display Highly Scalable Works as a scalable TX/RX matrix over the dedicated IP network and allows up to 256 total units, and extends/splits HDMI signals to multiple displays. The additional receiver unit (part#- CE-H26U11-S1) is sold separately Note: IGMP Gigabit Switch is recommended for best performance and reliability VLAN setup supported* Create a separate VLAN for each TX and its corresponding RX’s Note: - Each VLAN can only accommodate 1 transmitter (TX) - We recommend using SIIG's 24-port AV Over IP Smart Ethernet Switch (part# CE-SW0111-S1), sold separately Multiple Connectivity Ports* Comes with one HDMI video input port, eight HDMI output ports, eight RJ45 network input ports, eight RJ45 network output ports, one 3.5mm IR emitter port, eight 3.5mm IR receiver port, five reset buttons, one DC power jacks (12V/3A, for TX only), eight DC power jack (5V/1A, for RX) Connection Maximum Compatibility Supports Plug-n-play. No driver installation required The reset button allows displays to be re-detected if no displays are detected Metal Housing Design Protects the inside PCBA, also enhance the heat dissipation for better performance. Military-grade component for long service life Applications Video conference room Show room Digital signage Broadcasting Airport Control center Classroom Dental office Hospitality Supermarket Shopping center Sport bar Restaurant Retail Trade show Church Security center Surveillance control center Need to Know Before Buying 1. Please confirm your computer or device with HDMI port 2. Check the extended displays/monitors with HDMI port and support 1080p@60Hz resolution 3. Please ensure using UTP Cat5e or Cat6 cable for the best video quality and accurate transmission distance 4. IGMP Switch or Managed Ethernet Switch is recommended for the best performance and reliability

Specifications

Interface
Package Contents

Specifications

Video
HDMI	1x input, 8x output
Resolution	1080p/1080i/720p/480i/480p @60Hz
Transport protocol
HDbitT protocol	Audio/video digital connection transmission protocol
Audio
Stereo audio from HDMI, support 192Kbps bit rate
IR pass-through
Allows remote control of the HDMI source device and playback function at the remote display Full frequency: 20KHz to 60KHz
Power
Power adapter	Input: 100-240V/50-60Hz, Output: DC 12V/3A (TX); DC 5V/1A (RX)
UL listed	E335801/Level: VI
Environmental conditions
Operating temperature	32 to 122 degrees F
Storage temperature	14 to 158 degrees F
Relative humidity	0% to 90% RH (non-condensing)
Product Info
Transmitter unit (TX)	Dimensions: 11.81” (L) x 1.18” (H) x 4.37" (W) Weight: 1.81lbs Color: black Housing material: metal (Housing with wall mount design)
Receiver unit (RX)	Dimensions: 3.81” (L) x 0.93” (H) x 3.70" (W) Weight: 0.33lbs Color: black Housing material: metal (Housing with wall mount design)
Unit package
Dimensions	18.11” (L) x 6.30” (H) x 10.24" (W)
Weight	9.49 lbs
Certifications/Standards
FCC, CE, RoHS, REACH
Warranty: 2 years limited
Country of origin: China
