200W GaN PD Combo Charger - 3C1A

• Features
• Applications
• Need to Know Before Buying

---

Overview

Powerfull 4-Port high-power charger with three USB-C PD 3.0, Fast Charger 2.0, PPS and one USB-A Quick Charge 3.0 fast charging ports, Supports maximum 200W output totally, C1/C2 up to 100W, C3 up to 65W, USB-A up to 60W

---

Features

This 200W Gan PD Combo Charger with three USB-C charging ports, one USB-A charging ports, and Gallium Nitride 2 (Gan²) Pro technology make the best power charging efficiency



---

New GaN² Pro
Built-in the new semiconductor material achieves low heat temperature, higher charging efficiency, hard, and smaller size. Allows operation at higher voltages and switching frequencies, is more powerful and durable, and offers multiple protections to protect your devices from Over-load, Over-Current, Short-Circuit, and Over-Voltage



---

PFC Technology
Support the PFC (power factor correction) feature to enhance the power energy efficiently and to reduces the amount of reactive power generated by a PC or device

---

200W Fast Charging/QC 3.0
Provides a total 200 watts power output- Max. 2x USB-C 100W (USB-C1 & 2) charging ports, 1x USB-C 65W (USB-C3) charging port and 1x USB-A 60W (USB-C4) charging ports enable fully charge laptops, smartphones and tablets simultaneously





* Note: when USB-C and USB-A are used together, they only have Max. 24W shared (5V/2.4A +5V/2.4A)

---

Power Source
Offers Power Delivery 3.0 (PD 3.0), Fast Charging 2.0, and Programmable Power Supply (PPS) technologies to meet most USB-C power devices, and Quick Charger 3.0 (QC 3.0) compliant with USB-A power device for reliable and stable power

---

Multiple Connectivity Port
Comes with two USB-C charging ports (Max. 100W), one USB-C charging ports (Max. 65W), one USB-A (Max. 60W), AC power jack (200W)



Connection



---

ABS Housing Design
Smooth ABS housing with heat dissipation design for reliable performance and increase efficiency

---

Applications

• Office
• Meeting room
• Workstation
• Home
• Restaurant
• Hotels
• Resorts
• Classroom
• Library
• Airports
• Travel

---

Need to Know Before Buying

1. Make sure your laptop, smartphone, tablet, or other power devices with USB-C or USB-A port



2. Before charging, please use the original USB charging cable from your smartphone, tablet or other power devices for optimal charging efficiency

3. Always unplug the charger from the power source when not in use

• Interface
• Package Contents

---

Specifications

Power
Power adapter	Input: AC 100-240V / 50-60Hz, Output: AC 200W
USB-C1 & C2 charging ports (PD)	DC 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/5A (Max.100W)
USB-C3 charging port (PD)	DC 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3.25A (Max. 65W)
USB-A charging port (QC 3.0)	DC 5V/4.5A, 5V/3A, 9V/3A, 12V/3A, 20V/3A (Max. 60W)

Auto Adjustment Power Delivery
1-Port	2-Port	3-Port	4-Port
USB-C1 100W	USB-C1+C2 100W+100W	USB-C1+C2+C3 100W+65W+30W	USB-C1+C2+C3+USB-A 100W+65W+ (12W+12W)* *share 24W
USB-C2 100W	USB-C1+C3 100W+65W	USB-C1+C2+USB-A 100W+65W+30W
USB-C3 65W	USB-C1+USB-A 100W+60W	USB-C2+C3+USB-A 100W+(12W+12W)* *share 24W
USB-A 60W	USB-C2+C3 100W+65W
	USB-C2+USB-A 100W+60W
	USB-C3+USB-A (12W+12W)* *share 24W

Protection circuit module
Over-Current, Over-Voltage, Over-Charge, and Short-Circuit protection
Environmental conditions
Operating temperature	14 to 104 degrees F
Storage temperature	-4 to 158 degrees F
Relative humidity:	5% to 95% RH (non-condensing)
Product Info
Dimensions	3.26” (L) x 1.38” (H) x 2.48” (W)
Weight	0.66 lbs
Color	White
Housing material	Plastic
Unit Package
Dimensions	4.72” (L) x 1.57” (H) x 6.30” (W)
Weight	1.05 lbs
Certifications/Standards
FCC, RoHS 2.0, REACH, ETL
Warranty: 2 years limited
Country of origin: China

---

Interface



Input:

• 1x AC power jack (200W)

Output:

• 3x 24-pin, USB-C charging, Female
• 1x 4-pin, USB-A charging, Female

---

Package contents

• 1x 200W GaN PD Combo Charger - 3C1A
• 1x AC power cord, 1m
• 1x Carrying pouch
• 1x User reference guide
