HDMI HDbitT Over IP Extender with IR - 120m - One to One / One to Many - Reset key

• Features
• Applications
• Need to Know Before Buying

---

Overview

HDMI HDbitT Over IP Extender with IR, 1080p@60Hz, Extends HDMI signal up to 394ft (120m) by Over IP via Cat5e/6/7 cable with IR , support one to one, one to many

---

Features

Extend HDMI audio and video signals up to 394ft (120m) via Cat5e/6/7 cable for remote display/monitor using best network transport protocol and IR remote control of source devices



---

What is HDbitT?

HDbitT is a new generation audio/video digital connection transmission protocol solution. Provides stable performance, long-distance transmission, and high-definition signal



---

Extend Distance

This HDMI HDbitT over IP Extender with IR designed for transmission/security, HDMI signals up to 394ft (120m) through HDbitT protocol and Gigabit Ethernet switch to a remote HDMI display



---

Highly Scalable

Works as a scalable TX/RX matrix over the dedicated IP network and allows up to 256 total units, receiver(RX) units up to 255, and extends/splits HDMI signals to multiple displays. The additional receiver unit (part#- CE-H26U11-S1) is sold separately

*Note: IGMP Gigabit Switch is recommended for best performance and reliability










VLAN setup supported

Create a separate VLAN for each TX and its corresponding RX’s

---



Full HD Resolution

Supports high-definition video resolution up to 1080p (1920x1080) @60Hz, HDCP 1.2 to deliver a clear picture quality

---

IR Extension

IR pass-through feature allows remote control of the HDMI source device and playback function at the remote display

---

High Performance

Offers a true 10.2Gbps video bandwidth and supports stereo audio



---

Multiple Connectivity Ports

Comes with one HDMI video input port, one HDMI output port, two RJ45 network ports, one 3.5mm IR emitter port, one 3.5mm IR receiver port, two reset buttons, two DC power jacks (5V/1A)



Connection



---

Maximum Compatibility

Supports Plug-n-play. No driver installation required The reset button allows displays to be re-detected if no displays are detected

---

Metal Housing Design

Protects the inside PCBA, also enhance the heat dissipation for better performance. Military-grade component for long service life

---

Applications

• Digital signage	• Broadcasting	• Video conference room	• Show room	• Classroom	• Dental office
• Hospitality	• Supermarket	• Shopping center	• Sport bar	• Restaurant	• Retail
• Trade show	• Church	• Airport	• Control center	• Security center	• Surveillance control center

---

Need to Know Before Buying

1. Please confirm your computer or device with HDMI port



2. Check the extended display/monitor with HDMI port and supports 1080p@60Hz resolution



3. Please ensure using UTP Cat5e, Cat6 or Cat7 cable for the best video quality and accurate transmission distance

4. IGMP Switch or Managed Ethernet Switch is recommended for the best performance and reliability

• Interface
• Package Contents

---

Specifications

Video
HDMI	1x input, 1x output
Resolution	1080p/1080i/720p/480i/480p @60Hz
Transport protocol
HDbitT protocol	audio/video digital connection transmission protocol
Audio
Stereo audio from HDMI, support 192Kbps bit rate
IR pass-through
allows remote control of the HDMI source device and playback function at the remote display Full frequency: 20KHz to 60KHz
Power
Power adapter	Input: 100-240V/50-60Hz, Output: DC 5V/1A
UL listed	E335801/Level: VI
Environmental conditions
Operating temperature	32 to 104 degrees F
Storage temperature	14 to 158 degrees F
Relative humidity	5% to 90% RH (non-condensing)
Product Info
Transmitter unit (TX)	Dimensions: 3.70” (L) x 0.93” (H) x 3.81" (W) Weight: 0.33lbs Color: black Housing material: Aluminum metal (Housing with wall mount design)
Receiver unit (RX)	Dimensions: 3.70” (L) x 0.93” (H) x 3.81" (W) Weight: 0.33lbs Color: black Housing material: Aluminum metal (Housing with wall mount design)
Unit package
Dimensions	7.87” (L) x 3.15” (H) x 5.90" (W)
Weight	1.28 lbs
Certifications/Standards
FCC, CE, RoHS, REACH
UPC code: 662774044750
Warranty: 2 years limited
Country of origin: China

---

Interface



Transmitter unit (TX):

• 1x 19-pin, HDMI, Female (input)
• 1x 3.5mm infrared jack, IR emitter (output)
• 1x 8-pin, RJ45 (output)
• 1x Reset button
• 1x DC power jack, 5V/1A

Receiver unit (RX):

• 1x 19-pin, HDMI, Female (output)
• 1x 3.5mm infrared jack, IR receiver (input)
• 1x 8-pin, RJ45 (input)
• 1x Reset button
• 1x DC power jack, 5V/1A

---

Package contents

• 1x HDMI HDbitT Over IP Extender with IR - 120m
• 1x 3.5mm IR emitter extension cable
• 1x 3.5mm IR receiver extension cable
• 2x DC power adapter (5V/1A)
• 1x User Reference Guide
