I/O |
SKU:
LB-US0114-S1
USB 3.0 4-Port (Ext) PCIe Host Card
USB PCIe Card
4-Port USB-A
5Gbps
5V/900mA
UASP
Regular price
$49.99
Unit price
/
Unavailable
Shipping calculated at checkout.
USB 3.0 4-Port (Ext) PCIe Host Card is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Product Features
Adds 4 USB 3.0 Ports
Adds 4 USB 3.0 Ports
High-Speed Data Transfer
High-Speed Data Transfer
UASP Enhanced Storage Speed
UASP Enhanced Storage Speed
Powered Ports with Protection
Powered Ports with Protection
Molex Power Connector Required
Molex Power Connector Required
No content found
| Chipset | Renesas uPD720201 |
| Bus Connector | PCI Express x1 |
| Version | PCI Express 2.0 |
| Data Transfer Rate | Up to 5Gbps |
| USB Power Output | Up to 900mA |
| Connectors | |
| External | 4 x 9-pin USB 3.0 Type A, Female |
| Internal | 1 x 4-pin Molex Power Connector |
| Environmental Conditions | |
| Operating Temperature | 32 to 140 degrees F |
| Storage Temperature | 14 to 158 degrees F |
| Relative Humidity | 5% to 90% RH (non-condensing) |
| Certifications/Standards | FCC, CE, RoHS |
| UPC Code | 662774-040165 |
| Warranty | 1 year limited |
| Country of Origin | China |
| Package Contents | 1x USB 3.0 4-Port (Ext) PCIe Host Card 2x Spare Screws 1x Driver CD 1x Installation Guide |
| Product | |
| Dimensions (L) x (H) x (W) | 3.07" x 4.72" x 0.79" 7.80 cm x 12.00 cm x 2.00 cm |
| Weight | 0.10 lbs (0.05 kg) |
| Color | Black |
| Unit package | |
| Dimensions (L) x (H) x (W) | 7.28" x 5.43" x 1.30" 18.50 cm x 13.80 cm x 3.30 cm |
| Weight | 0.28 lbs (0.13 kg) |
| Master Carton | |
| Dimensions (L) x (H) x (W) | 15.16" x 13.78" x 11.50" 38.50 cm x 35.00 cm x 29.20 cm |
| Weight | 13.23 lbs (6.00 kg) |
| Quantity | 40pcs/ctn |
| System Requirements | - Desktop PC with one available PCI Express (PCIe) slot - Windows® 10 (32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/64-bit) / Vista (32-/64-bit) / XP (32-/64-bit) - Windows® Server 2016 (32-/64-bit) / 2012 R2 / 2012 (32-/64-bit) / 2008 R2 / 2008 & 2003 (32-/64-bit) Note: Molex power connection is required |
