1x2 HDMI 4K HDR Splitter with EDID

Overview

Features

•

  Lightweight and Compact HDMI Splitter

  You will barely notice it's there


  This 1 in 2 out 4k hdmi splitter distributes HDMI video and audio from a single source to up to 2 HDMI displays simultaneously, with 4K HDR and EDID management, without signal degradation.

  Highlights

  • Compact size makes this 1x2 HDMI splitter taking up virtually no space on your desk or shelf
  • Easy to set up, so all you need to do is to plug it in to the HDMI cables and plug in the power
  • Compatible with most of streaming devices on the market, such as Apple TV, Chromecast with Google TV, Amazon Fire TV Stick 4K, Roku Ultra and Streaming Stick 4K, and so on
  • LED EDID indicator allows you to select 4 flexible EDID options to adapt to different setups. Switch to Auto EDID Analysis Learning Mode for best compatibility

  Great Solution when You Want One Signal on 2 TVs



  	CE-H26J11-S1	CE-H26K11-S1
  Input x Output	1x2	1x4
  Max Resolution / HDR	4K @60Hz 4:4:4 / HDR	4K @60Hz 4:4:4 / HDR
  HDMI / HDCP	2.0a / 2.2	2.0a / 2.2
  EDID	✓	✓

  4 EDID Modes LED indicator allows you easily identifying EDID status. * Note: Default setup Red 4K UHD 7.1 channel audio -- Red = 4Kx2K 60Hz, 8/10/12bit, 3D, HDR Video, 7.1ch Audio Blue = 4Kx2K 60Hz, 8/10/12bit, 3D, HDR Video, 2ch Audio Green = Auto EDID Analysis Learning Mode Yellow = EDID Learning Mode	4K HDR Compatible Resolution is up to [email protected] YUV 4:4:4 8bit or [email protected] YUV 4:2:0 10-bit HDR	What's in the Box 1x2 HDMI 2.0 4K HDR Splitter with EDID Power Adapter Quick Start Guide

Specifications

• Chipset: EP91X2
• Compliant with HDCP 2.2/1.4 specifications
•  Audio: xvYCC, x.v.Color and Deep Color
• Resolution: Up to [email protected] YUV 4:4:4 8bit, [email protected] YUV 4:2:0 10bit HDR
• Video bandwidth: Up to 18Gbps (single-link 600MHz)
• Video: 480p/720p/1080i/1080p/HDR [email protected] (YUV 4:2:0 10bits)/[email protected] (YUV 4:4:4 8bits)
• EDID modes:

  • Red LED: [email protected], 8/10/12bit, 3D, HDR, 7.1ch
  • Blue LED: [email protected], 8/10/12bit, 3D, HDR, 2ch
  • Green LED: Auto EDID analysis - use the EDID of the display with the lowest resolution
  • Yellow LED: EDID learning - use the EDID of the display connected to HDMI Output 1
• Audio: DTS-HD Master Audio, Dolby TrueHD, Dolby Digital, DTS, DVD-Audio, LPCM, SACD, MPCM
• ESD protection: ±15kV Air / ±8kV Contact
• HDMI cable length:

  • [email protected]: Up to 10 meters (5m/In ; 5m/Out)
  • 1080p & [email protected]: Up to 15 meters (5m/In ; 10m/Out)
• Product:

  • Dimensions: 2.77" (L) x 0.91" (H) x 1.98" (W)
  • Weight: 0.17 lbs
  • Color: Pantone 425C
  • Housing material: Aluminum
• Connectors:

  • 1x 19-Pin, HDMI, Type A, Female, Input
  • 2x 19-Pin, HDMI, Type A, Female, Output
  • 1x Push button, EDID selection
  • 15-Pin, Micro-USB, Female, Power
• Unit package:

  • Dimensions: 9.1" (W) x 1.7" (H) x 3.9" (D)
  • Weight: 0.50 lbs
• Power adapter:

  • Input: 100-240VAC, 50/60 Hz
  • Output: DC 5V/1A
  • UL Listed: E135856 / Level: VI
• Environmental conditions:

  • Operating temperature: 32 to 104 degrees F
  • Storage temperature: -4 to 140 degrees F
  • Relative humidity: 20 to 90% RH (non-condensing)
• Certifications/Standards: FCC, CE, RoHS
• TAA compliant
• Warranty: 3 years limited
• Country of origin: Taiwan

Package contents

• 1x2 HDMI 4K HDR Splitter with EDID
• Power Adapter
• Quick Start Guide
