Presentation Switches

Part No. CE-H26S11-S1 CE-H26611-S1 CE-H25Y11-S1 CE-H25Z11-S1 CE-H24111-S1 CE-H24311-S1 CE-H25Q11-S1
siig logo CE-H26S11-S1 CE-H26611-S1 CE-H25Y11-S1 CE-H25Z11-S1 CE-H24111-S1 CE-H24311-S1 CE-H25Q11-S1
Input x Output 5 x 3 2 x 1 Receiver 4 x 1 6 x 1 9 x 1 3 x 1
Compliant Standard DP 1.2/HDMI 2.0 / HDCP 2.2 HDMI 2.0 / HDCP 2.2 /1.4 IEEE 802.11 a/g/n/ac 2.4Hz & 5GHz HDMI 2.0 / HDCP 2.2 /1.4 IEEE 802.11 a/g/n/ac 2.4Hz & 5GHz HDMI 2.0 / DP 1.2 Alt-mode HDMI 1.4 / HDCP 1.4 HDMI 1.4 / HDCP 2.2 DP 1.2 / HDMI 2.0 / HDCP 2.2
Support External Displays 2 + 1 1 1 1 1 1 1
Video format Input HDMI x 3 / DisplayPort/
USB-C
HDMI / Wireless Wireless HDMI x 2 / USB-C (Alt mode)/ Wireless HDMI x 4 / VGA x 2 HDBaseT / DP / HDMI x 5 / VGA x 2 HDMI / Mini DP / USB-C
Video format output HDMI x 2 / HDBaseT x 1 HDMI HDMI HDMI HDMI HDMI / HDBaseT HDMI
Resolution Up to 4K60Hz On base unit up to 4K60Hz From HDMI Dongle up to 4K30Hz On base unit up to 4K60Hz From HDMI Dongle up to 4K30Hz HDMI input up to 4K60Hz
HDR
USB-C input up to 4K30Hz
Wireless input up to 4K30Hz
HDMI input up to 4K 30Hz
VGA input up to 1080p 60Hz
HDMI input up to 4K 60Hz 420
VGA input up to 1080p 60Hz
Up to 4K 60Hz
Audio 3.5mm Mic in 3.5mm Stereo 3.5mm Stereo 3.5mm Stereo
5-pin audio terminal block
3.5mm Stereo
3-pin audio Terminal block
S/PDIF Audio
3-pin audio Terminal block
5-pin audio Terminal block
RS-232 3-pin Terminal block 3-pin Terminal block 3-pin Terminal block 3-pin Terminal block 3-pin Terminal block
USB Micro USB for FW
USB 2.0 for Pen Drive
USB 2.0 / USB-C 3.1 Gen 1 USB 2.0 / USB-C 3.1 Gen 1 USB-A 3.0 x 2 for device
USB-B 3.0 x 2 for Source
Micro USB for FW
USB 2.0 for FW USB power input
Switching Button software / Wireless Dongle software / Wireless Dongle Button button / remote control button / remote control
IR V V
Part# CE-H26S11-S1 CE-H26611-S1 CE-H25Y11-S1 CE-H25Z11-S1 CE-H24111-S1 CE-H24311-S1 CE-H25Q11-S1
Network Gigabit PoE / Ethernet Gigabit PoE / Ethernet V
Control USB Software software / Web GUI software / Web GUI panel button USB FW / RS-232 / 3.5mm IR USB FW / RS-232 / 3.5mm IR / TCP/IP
Additional Features Video 1080p Recorder up to 16 units / Airplay / Wireless
Midia for Android / Security
Levels
up to 16 units / Airplay / Wireless
Midia for Android / Security
Levels
Airplay / Miracast / Touch
screen support
Mountable Mountable / Web GUI / OSD
COO TAA China China China China China China
