USB 2.0 HD Video Capture Slim Box - Multi-Input

Easily capture and save videos from HDMI or AV (Composite/S-Video) video source such as DVD players, media players, or Set-top boxes

Discontinued

SKU

JU-AV0312-S1

Join our free Membership Program and save 5% off every order

We ship all orders within 1 business day

Lifetime technical support on all of our products

45-day return window and money-back guarantee

Overview

Features Features Converts analog video to digital DVD or VCD formats Easily capture and save videos from HDMI or AV (Composite or S-Video) video sources such as DVD players, media players, or Set-top boxe. Note: Does not allow capture of HDCP protected signals Built-in high performance H.264 Hardware encoder chip, allows you to watch the video while recording Supports up to 1080p HDMI source and 480p AV source for capturing Portable design, easy to carry and store Recording video@ H.264AVC and audio@ H.264 AAC

Specifications

System Requirements Package Contents Specifications Chipset: Fujitsu MB86H58 HDMI compliance: does not allow HDCP protected signals to be recorded SoC: H.264 Hardware compression SoC Bundled with VivaCAP app for Android for video capture on Android OS tablets Bundled with CyberLink PowerDirector and Media Espresso advanced authoring tools for PC to improve usability and provide quicker operation. Note: Does not allow capture of HDCP protected signals Built-in H.264 real-time hardware encoder Capture up to 1080p@30fps Capture format: hardware compressed MPEG-4 (H.264/ AVC) Input resolution: HDMI: Up to 1080p@30fps AV (Composite or S-Video): Up to 480p@30fps Product: Dimensions: 3.39" (H) x 1.97" (W) x 0.67" (D) Weight: 0.09 lbs Color: Black Cables: A/V Fan-out: S-video: Input Composite video: Input L/R audio: Input Mini USB: Output Mini USB (M) to USB Type-A (M) Mini USB (M) to Y-split USB Type-A (M) & Micro USB (M) Connector: 1 x 4-pin, USB Mini-B, Female, Output 1 x 19-pin, HDMI Type-A, Female, Input 1 x 10-pin, Mini-B, Female, AV (Composite, S-Video) , Input Environmental conditions: Operating temperature: 32 to 131 degrees F Storage temperature: 14 to 149 degrees F Relative humidity: 10 to 90% RH (non-condensing) Certifications/Standards: FCC, CE, RoHS Warranty: 2 years limited Country of origin: China System Requirements PC or Mac computer with an available USB port 2.4GHz Dual Core CPU with 2GB RAM Graphics Card with DirectX 9.0c Sound card compatible with AC97 Windows^® 10 (32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/64-bit) Mac OS X^® 10.9 / 10.10 Android^TM 4.2 or later Package contents USB 2.0 HD Video Capture Slim Box - Multi-Input Mini USB Cable to USB Type A cable A/V fan-out cable Mini USB to USB Type A + Micro USB Y cable Driver CD CyberLink PowerDirector Software CD Installation guide

Channel Codes

Ingram Micro: 1V1620
Tech Data: 11896616
D&H: JUAV0312S1
ASI: 175568
Synnex: 4338355

Downloads

Q&A

No Questions

Please note that you must be logged in to submit questions.

Your question:

Your name:

get notification on email when the answer is ready

Your e-mail:

Mac OS X 10.12 / 10.11	Download driver MAC OS X 10.11: v1.2.0.13
Windows 10 (32-/64-bit) / 8.x (32-/64-bit) / 7 (32-/64-bit); Mac OS X 10.9 / 10.10; Android 4.2 or later (requires installing VivaCap app from Play Store)	Download driver & software Windows driver: v1.0.15.0612: Mac: iCAP v1.2.0.13
