Features

Freely Rotate Your Monitor to Help You Effectively

• Design to fit LED/LCD/Plasma displays from 17" to 35”
• Hold your monitor max 33 Ibs each

Easy to Position with One Hand

Fit Two Monitors 17" to 35"

Better Compatibility It supports VESA mounting patterns up to 200x200 mm for larger and heavier monitors.	Keep Your Options Open With the tillable VASA panel design, you could effortlessly switch between portrait or landscape displays.	Easy to Adjust Simply turn the shock five times, then test if the tension is holding the monitor sturdily.	Two Mounting Options The two options to mount this desk arm on the table, C-clamp and Grommet bases are both included in the package for a quick and easy installation.

CE-MT3011-S1 Tech Specs

	CE-MT3011-S1	CE-MT3211-S1	CE-MT3K11-S1	CE-MT2E12-S1	CE-MT3E11-S1	CE-MT2X11-S1
Max Screen Size	35 inch	35 inch	32 inch	32 inch	30 inch	32 inch
Max Arm Capacity	33 lbs each display	33 lbs each display	19.8 lbs each display	19.8 lbs each display	17.6 lbs each display	19.8 lbs each display
Max Arm Lift	23"	23"	18"	18"	17.7"	32.6"
Max Arm Extend	20.7“	20.7“	21.6“	23.8“	15.5“	25.3“
Spring Type	Gas Spring	Gas Spring	Gas Spring	Gas Spring	X	Gas Spring
Mount Type	C-clamp & grommet	C-clamp & grommet	C-clamp & grommet	C-clamp & grommet	C-clamp & grommet	C-clamp & grommet
Cable Management	✔	✔	✔	✔	✔	✔

Specifications

• Screen size: 17" to 35" (measured diagonally) or Dual 43" 16:9 monitors.
• Monitor weight capacity: Maximum 33 lbs (each monitor)
• Tilt angles: ±45° (upward/downward)
• VESA Rotation: ±90°
• VESA swivel: ±90°
• Arm swivel: ±180°
• Pan swivel: ±135°
• Height adjustment: 8.9"~23"
• VESA mounting: 75x75mm, 100x100mm, 200x200mm
• Suggested desktop thickness: 0.40" to 3.3" (Clamp) & 0.4" to 1.88" (Grommet)
• Desktop overhang: Minimum 3.25 inches (C-clamp mount only)
• Color: Black
• Material: Aluminum / Plastic
• Product dimension: 47.91" (W) x 31.69" (H) x 5.04" (D)
• Product weight: 19.69 lbs
• Unit Package:
  • Dimensions: 20.67" (W) x 5.71" (H) x 13.07" (D)
  • Weight: 22.27 lbs
• Certifications/Standards: RoHS
• Warranty: 2 years limited
• Country of origin: Engineered in USA , Manufactured in China

Package contents

• Dual Monitor Heavy-Duty Premium Aluminum Gas Spring Desk Mount - 35"
• Installation kit
• Installation guide
