Dual Head Full HD HDMI Video Docking Station

  • USB-A to USB-B Input
  • Dual View
  • [email protected]
  • 2x HDMI
  • DisplayLink IC
  • 2x USB-A 3.0 5Gbps
  • 4x USB-A 2.0
  • 1x Gigabit Ethernet
  • Headset Jack
  • 3 Display Modes
  • USB-A to USB-B Cable
  • Windows & Mac
Out of stock
SKU
JU-DK0L11-S1
$199.99

We will send this product within 1 business day

Lifetime technical support on all of our product

45 day return and money back guarantee



    Overview

    Advanced docking station adds two HDMI 1080p displays, 6 USB ports, a Gigabit Ethernet port, and a stereo audio/microphone connectivity to Windows and Mac computers. Compliant with mac® system for M1 and M2


    Features

    Transforms a single USB-A port of your computer into multiple connections with a DisplayLink USB graphics technology and provide dual HDMI displays making this docking station more powerful, productive, and high performance

    fea

    *Note:
    This Dual Head Full HD HDMI Video Docking Station is recommended with web and productivity software, not for gaming, and cannot be mixed with non-DisplayLink USB adapters

    fea2

    m1m2


    Video Resolution
    Supports up to [email protected] Full HD video display through two HDMI ports and 5.1ch surround sound

    res

    Monitor Solutions:
    res2

    Three Display Modes
    Provides Mirror, Extended, and Primary video modes, streaming video to HDTV monitors and projectors for the perfect visual display

    Modes


    High Performamce
    Expand multiple connectivity ports to your USB-A computer to increase your efficiency. This Dual Head Full HD HDMI Video Docking Station is fully certified to meet DisplayLink certification

    DisplayLink graphics technology works with any computer, connector types and connect multiple displays functionality to increase in work productivity. Compatible with USB-A

    DisplayLink


    Multiple Connectivity Ports
    Adds one USB 3.0 Type-B port (includes USB-A to USB-B cable for easy conversion), two HDMI video outport ports, two USB 3.0 Type-A, four USB 2.0 Type-A, one Gigabit Ethernet, and one 3.5mm audio jack to connect headphones / Stereo speakers or microphone input

    Ports

    Connection
    Connection


    USBUSB Data Transfer
    Delivers two SuperSpeed USB 3.0 Type-A ports up to 5Gbps data transfer rate on the front side and four High Speed USB 2.0 Type-A ports up to 480Mbps data transfer rate for keyboard, mouse, Flash drive, Printer, and other USB. peripheral devices


    RJ451G Ethernet Data Transmission
    Up to 1,000Mbps data transfer rate and seamless backward compatible with 10/100 Mbps


    Maximum Compatibility
    - Compliant with mac® system for M1 and M2
    - Compatible with Windows® 11/ 10 / 8.1 / 8 / 7 and macOS® 11 / 10.15 to 10.10

    *Note:
    1. not compatible with macOS ®10.13.4 to 10.13.6 and recommended to upgrade to macOS®10.14 or later or stay with 10.13.3 or earlier
    2. Uninstall any legacy DisplayLink driver (v5.2.5 or earlier) and install the latest driver (macOS® 10.15.6 or later) on SIIG’s website
    3. Does not support movie/video playback via iTunes and HDCP protected content via Safari web browser (Netflix, Amazon Prime, Hulu, HBO Go, etc.)


    ABS Housing Design
    Vertical design and smooth ABS housing with heat dissipation design for reliable performance, increase efficiency, and save space


Applications

    • Media editing
    • Workstation
    • Web design studio
    • Home
    • Educational facilities
    • Financial
    • Office
    • Receiption room
    • Medical office

    Need to Know Before Buying

    1. Please make sure your computer has a USB-A connector and use the included USB-A to USB-B cable to connecting this Dual Head Full HD HDMI Video Docking Station

    Computer

    2. Check the extended displays/monitors resolution that support [email protected] and has HDMI port on each display

    monitor

    3. Before connecting the USB 3.0/2.0 port, make sure your peripheral device has a USB 3.0 port or USB 2.0 port

    4. Compliant with mac® system for M1 and M2


    Specifications

    Hardware
    Chipset DisplayLink DL-3900
    Software
    OS Compatibility Windows® 11 & mac OS® 12 or newer
    Video
    HDMI 1080p @60Hz, 2 ports
    Resolution 1080p / 1080i / 720p / 480p
    USB 3.0 2x Type-A, data transfer rate up to 5Gbps and compatible with USB 2.0 specification
    USB 2.0 4x Type-A, data transfer rate up to 480Mbps and compatible with USB 1.1 specification
    Audio
    5.1 channel surround sound from HDMI output
    2 channel stereo audio from 3.5mm audio jack
    Display Mode
    Mirror, Extended, Primary video modes
    Power Adapter
    Input AC 100-240V / 50-60Hz
    Output DC 12V/2A
    UL Listed E221556 /Level: VI
    Ethernet
    Data transfer rate: up to 1G (1000Mbps), backward compatible with 10/100Mbps
    Supports IEEE 802.3x Full Duplex flow operation, crossover detection and auto-correction
    Compatible with IEEE 802.3, 802.3u
    Environmental conditions
    Operating temperature 32 to 104 degrees F
    Storage temperature 14 to 158 degrees F
    Relative humidity: 10% to 90% RH (non-condensing)
    Product Info
    Dimensions 5.31” (L) x 7.36” (H) x 2.87" (W)
    Weight 0.75 lbs
    Color Black
    Housing material

    ABS

    Unit package Dimensions: 8.07" (W) x 5.51" (H) x 4.33" (D)
    Weight: 1.54 lbs
    Certifications/Standards
    FCC, CE, RoHS
    Warranty: 2 years limited
    Country of origin: Thailand

    Interface

    Interface

    Input:

    • 1x 9-pin, USB 3.0 Type-B, Female (PC Input)
    • 1x DC power Jack

    Output:

    • 2x 19-pin, HDMI, Female
    • 2x 9-pin, USB 3.0 Type-A, Female
    • 4x 4-pin, USB 2.0 Type-A, Female
    • 1x 8-pin, RJ45, Gigabit Ethernet, Female
    • 1x 3.5mm Audio Jack (Headset/Mic)

    System Requirements

    • Desktop or laptop computer with an available USB 3.0 Type-A port
    • Compliant with mac® system for M1 and M2
    • Windows® 11 (64-bit) / 10 (32-/64-bit) / 8.1 (32-/64-bit) / 8 (32-/64-bit) / 7 (32-/64-bit)
    • macOS® 12 to 10.10*
      *Note: Our adapter is not compatible with 10.13.4 to 10.13.6

    Package contents

    • Dual Head Full HD 1080p HDMI Video Docking Station
    • Power Adapter 12V/2A
    • USB 3.0 A to B cable
    • Driver CD
    • User manual

Manuals

Drivers


Hardware Version: 1

macOS Monterey 12 / Big Sur 11
Download DisplayLink Manager 1.7
Build: posix/60-3273-ged263b95dfa (120). For the latest MAC driver please visit, https://www.synaptics.com/displaylink/downloads/macos, and download the latest driver to maximize compatibility
Windows 8 (32-/64-bit)
Download driver version 9.3 M1
Windows 11 (32-/64-bit) / 10 (32-/64-bit) / 8.1 (32-/64-bit) / 7 (32-/64-bit)
Download driver version 10.3 M0
Software Package Version: 10.3.6419.0. Driver version: 10.3.6400.0


Hardware Version: 1

macOS X 10.10
Download driver version 3.1


Hardware Version: 1

macOS X 10.11.5 to 10.11
Download driver version 4.1


Hardware Version: 1

macOS X 10.13 to 10.13.3* / 10.12 / 10.11.6
Download driver version 4.3.1
*Note: Our adapter DOES NOT work with Mac OS 10.13.4 to 10.13.6 update. It's recommended to upgrade to Mojave 10.14 or later or stay with 10.13.3 or earlier.


Hardware Version: 1

macOS 10.14.x
Download driver version 5.2.6
Build: v5.2.6 (128)
macOS Catalina 10.15.x
Download DisplayLink Manager 1.5
For the latest MAC driver please visit, https://www.synaptics.com/displaylink/downloads/macos, and download the latest driver to maximize compatibility

Frequently Asked Questions (Q&A)

Q: Can I enable Clamshell mode or lid closed mode on my Macbook Pro?

Clamshell mode (lid closed) is supported on computers using Apple M1 silicon with external power connected (e.g. Apple MacBook power adapter or docking station with charging capability) on macOS Big Sur version 11.1 and later. Clamshell mode on Intel...
